MDC-W Series – Compact Wet Dust Collector

Product Overview

The MDC-W series is designed specifically for applications where installation space is restricted. With a horizontal airflow arrangement and compact structural layout, the unit minimizes installation height while maintaining effective wet scrubbing performance for moderate airflow applications.

Air Flow

7,000-50,000 m³/h

Pressure Drop

1600 – 2000 Pa

Collection Efficiency

Up to 99%

Installed Power

11 – 55 kW

Request a Proposal Download Inquiry Data Sheet

Product Structure

The MDC-W series is engineered with a space-efficient layout where major components are integrated into a compact footprint, making the unit suitable for retrofit projects and restricted plant layouts.

Wet dust collector,Wet Collector,wet scrubber

① Inlet
② Spray System
③ Venturi Rod Deck
④ Demister
⑤ Fan
⑥ Outlet

Advantages & Features

Designed around space efficiency, the MDC-W series focuses on compact footprint, simplified installation and practical maintenance access while maintaining dependable dust collection performance.

Venturi Separation System

The MDC-W series utilizes the MDC proven Venturi rod separation structure, dividing incoming airflow into multiple smaller Venturi channels. This design improves airflow uniformity while maintaining low pressure loss.

By increasing the number of gas-liquid contact zones, the system enhances dust capture efficiency while maintaining stable operating resistance. This structure provides an optimal balance between separation performance and energy efficiency for industrial applications.

High Efficiency Demisting Module

The MDC-W features a high-efficiency dual cyclonic demisting module designed to remove moisture from the exhaust air stream. The specially designed twin swirl separator effectively captures droplets and prevents moisture carryover.

This design improves downstream equipment protection and ensures consistent clean exhaust air, making the system suitable for applications requiring stable moisture separation performance.

Straight Through Airflow Design

The MDC-W adopts a straight-through airflow configuration, with inlet, Venturi section, demister, and fan arranged in a linear sequence. This design eliminates unnecessary bends and reduces airflow resistance.

The simplified airflow path improves system efficiency while the compact arrangement minimizes footprint, making the MDC-W especially suitable for installations where space is limited.

Integrated Industrial Fan System

The MDC-W integrates a high-performance centrifugal fan designed for industrial dust extraction duty. With static pressure exceeding 3500 Pa, the system provides reliable suction capacity for most applications.

The integrated design reduces installation complexity and improves operational stability while ensuring sufficient negative pressure for effective dust collection.

Optional Closed Loop Water System

The MDC-W can be equipped with an optional closed-loop water circulation system. Dust settles for discharge while clarified water is recirculated through a pump back to the spray system.

Integrated level monitoring and automatic refill functions allow stable operation while reducing water consumption and environmental discharge requirements.

Industrial Durability Design

The MDC-W is built for demanding industrial environments. All units undergo SA2.5 surface preparation followed by a heavy-duty triple coating system consisting of zinc-rich primer, micaceous iron oxide intermediate coating, and polyurethane topcoat.

This coating system provides excellent corrosion resistance and long service life even in harsh operating conditions.

Technical Specifications

Typical technical data of standard models are shown below for reference and preliminary selection.

Model	Air Flow (m³/h)	Power (kw)	Model	Air Flow (m³/h)	Power (kw)
W85	7000-8000	11	W140	18000-22000	30
W105	9000-12000	15	W160	22000-28000	37
W115	12000-14000	18.5	W170	28000-32000	45
W125	14000-17000	22	W190	33000-39000	55

* Capacity based on typical bulk density, data for reference only, final design prevails, dimensions subject to configuration.

Request a Proposal

Submit your project requirements and our engineers will recommend a suitable configuration for your application.

Frequently Asked Questions

Common questions about application range, dust control, and selection data.

Q: What kind of installation condition is the MDC-W suitable for?

A: It is particularly suitable for installation environments with limited space height or limited floor area.:contentReference[oaicite:9]{index=9}

Q: What is the key design feature of the MDC-W structure?

A: The Venturi rod layer, mist elimination device, and fan are arranged in a straight line to reduce resistance and improve airflow efficiency.:contentReference[oaicite:10]{index=10}

Q: Does the MDC-W avoid clogging risks?

A: Yes. The internal structure is designed without easily clogged components such as traditional defogging boards or wire mesh.:contentReference[oaicite:11]{index=11}

Q: What optional accessory is available?

A: An optional circulating water system can be equipped to further reduce sewage discharge and improve environmental performance.:contentReference[oaicite:12]{index=12}
